Self feeding drill units utilize a Pneumatic Feed with Hydraulic Feed Control and Electric Motor for spindle rotation. This combination offers much lower operating cost than fully Pneumatic Air Drills.
Self feeding drill units also have the drive torque for use with applications that require multi spindle heads.
There are many other Flex Stand models available. Various combinations can be selected depending on the machine layout.
Since 2007, we have helped thousands of companies improve their hole drilling production, improve the quality of their products requiring drilling or reduce their hole drilling costs.
| Model number |
Rotating speed |
Drilling capacity | Stroke | Motor | Thrust | Weight | |||
| Aluminum | Cast iron | Steel | Total stroke |
Cutting stroke |
Output | ||||
| min-1 | mm | mm | mm | kw | N | kg | |||
| PR3P | 700-7500 | 12 | 9.5 | 8.5 | 80 | 60 | 0.55 / 0.75 | 1200 | 21 |
| PR3PL | 120 | 100 | 25 | ||||||
| PR32P | 100 | 80 | 21 | ||||||
| PR32PL | 150 | 100 | 24 | ||||||
| PR4P | 330-6100 | 19 | 15.5 | 13 | 100 | 80 | 0.75 / 1.1 | 1800 | 31 |
| PR4PL | 150 | 130 | 36 | ||||||
| PR5P | 400-6100 | 20 | 17 | 16 | 100 | 80 | 1.5 / 2.2 | 2700 | 38 |
| PR5PL | 150 | 130 | 45 | ||||||
| PR6P | 200-3500 | 24 | 21 | 19 | 150 | 130 | 1.5 / 2.2 | 5200 | 100 |
